70W Rural Roadway Lamp
LED street lamps are different from conventional street lamps, LED light source uses low-voltage DC power supply, efficient white light synthesized by GAN-based power blue LED and yellow, With high efficiency, safety, energy saving, environmental protection, long life, fast response, high color index unique advantages, It can be widely used in roads. The outer cover can be made with high temperature resistance of 135 degrees and low temperature resistance of -45 degrees
- Product Introduction

Outdoor Led Lighting Landscape
LED street lamps are different from conventional street lamps, LED light source uses low-voltage DC power supply, efficient white light synthesized by GAN-based power blue LED and yellow, With high efficiency, safety, energy saving, environmental protection, long life, fast response, high color index unique advantages, It can be widely used in roads. The outer cover can be made with high temperature resistance of 135 degrees and low temperature resistance of -45 degrees
Got an elegant slim design, smooth surfaceavoids accumulation of sand, leave, snow and other stuff. One integrated PC lens brings high efficary 160lm/W.
Compact structure, light weight, 3 sizes from 25W to 150W with a compact design makes it super cost-effective. Pack several pieces of street lights in one carton, less volume saves your shipping cost.
Full wattage: 25w/40w/55w/75w/100w/120w/150w.
160lm/w, IP66 & IK09. Class I and Class II optional.
Interaged microwave sensor is available.
Photocell, 3/5/7 pins NEMA Socket and LoRa/Zhaga socket for smart city controls optional.
Various mounting adaptors for different applications.
Applications: Rural roadway, Parking lots, Residential streets, Plazas
Characteristics
|
AC input voltage |
100-277V,50/60Hz |
|
Factor of power |
>0.95 |
|
THD % |
< 15% |
|
Whole light effect |
130lm/W、150lm/W、170lm/W |
|
Lamp color temperature (CCT) |
4000K、5000K、6500K |
|
Luminance Indication (CRI) |
>70 |
|
External lightning protection level |
10kV standard (20kV optional) |
|
Control switch |
Time control, light control |
|
Intelligent lighting communication signal |
PLC、NB、LORA |
|
Height of installation |
5m To 10m |
|
Distance between lamps |
20m To 45m |
|
Operating temperature |
-40C~+50°C |
|
Storage temperature |
-40C~+50°C |
|
LED Brand |
Philips, Tiandian |
|
LED light fading |
L70 > 100000hrs |
|
Area of projection |
0.109m3 |
|
IP waterproof class |
IP66 |
|
IK Anti-impact rating |
IK08 |
|
Class of luminaires |
Class I |
|
Shell spray color |
7040 Warm white |
|
Light pole pipe diameter |
Φ25-Φ32 / Φ42-Φ48 / Φ52-Φ62 |
|
Size of appearance (mm) |
493×222×100 |
|
Size of package (mm) |
555×278×268 (2pcs/CTN) |
|
Main materials |
ADC12 die cast aluminum + toughened glass |
|
Standard of certification |
CQC、UL8800、UL1598、DLC、CE |
|
Quality assurance |
5 years (7 years optional) |
Size

Light Distribution Curve

|
Model |
Power(w) |
Luminaire light flux (lm) |
LED model |
LED number |
Height of installation |
Maximum distance between |
The net weight |
Gross weight |
PCS/CTN |
|
WMDSL001B70 |
70 |
9100 |
3030 |
80pcs |
5~8m |
<32m |
3.4kg |
7.5kg |
2pcs |
Installation Diagram

Bid bonus item, patent independent arm design, very firm

The replacement of LED light source and drive power should be operated by professionals or our staff
|
|
Warning - High pressure hazard, installation, must be professional installation |
| The light source, power supply, fittings, etc. contained in this lamp can only be replaced by the manufacturer |
Optional Accessories

20KV surge arrester

Safety wire rope

Air convection valve

Light controlled switch

Zhaga baseZhaga
Why choose us?
- We have a large inventory of products, ensuring fast and efficient order processing and delivery.
- In addition to being able to supply 70W Rural Roadway Lamp with general specifications, we are also able to customize it to meet the actual needs of our customers.
- We offer a variety of customization options, including color, size, and mounting options.
- We are sincerely looking for global partners for the future broad market prospect in various fields of the world.
- Our products are designed to maximize energy efficiency and reduce energy costs.
- We have modern machining equipment, complete testing methods, high-quality scientific and technological personnel, and rely on our professional level and mature experience in the field of 70W Rural Roadway Lamp to continuously provide customers with good products and services.
- We are a Chinese factory that manufactures high-quality street light products.
- The company attaches great importance to the research and discussion of 70W Rural Roadway Lamp theories, attaches importance to innovation, and constantly develops and explores new products.
- We provide ongoing support and assistance to our clients throughout the entire customer journey.
- With a good after-sales service system, we can solve various problems in after-sales service for customers.
Introducing the 70W Rural Roadway Lamp
Are you looking for an efficient and reliable lighting solution for rural roads? Look no further than the 70W Rural Roadway Lamp!
At our manufacturing facility in China, we have designed and produced this lamp with the needs of rural communities in mind. Here are some of the key features and benefits of our product:
Energy Efficiency: Each 70W lamp can provide the same level of illumination as a traditional 250W lamp, while using less energy. This means that communities can save money on their electricity bills and reduce their carbon footprint at the same time.
Long Lifespan: Our lamps are built with high-quality materials and workmanship to ensure a long lifespan of 50,000 hours. This means that communities can enjoy reliable lighting for years to come with minimal maintenance costs.
Durable Design: Our lamps are designed to withstand tough outdoor conditions, with an IP65 waterproof rating and an anti-corrosion aluminum housing. This means that communities can feel confident that their investment will withstand the elements and retain its quality over time.
Versatile Lighting: The 5700K color temperature of our lamps provides a bright white light that is ideal for illuminating rural roads. Plus, the adjustable beam angle allows communities to customize the lighting for their specific needs, whether that be a wider spread or a narrower focus.
Easy Installation: Our lamps come with a standard mount that can be easily installed on most poles or surfaces. Plus, the lightweight design makes it easy for communities to handle and install the lamps themselves, with no need for extra equipment or expertise.
Affordable Price: Despite all these impressive features and benefits, our lamps are priced at just 70 each. This means that communities can enjoy high-quality lighting without breaking the bank, making it accessible to even the most remote and underserved areas.
In summary, the 70W Rural Roadway Lamp offers an energy-efficient, long-lasting, durable, versatile, easy-to-install, and affordable lighting solution for rural communities in need. Contact us today to order your lamps and improve the safety and well-being of your community!
